Product Specifications
Vehicle Name Hualing Hanma Heavy Crane Chinese Brand Shenbai Heavy Industry
Engine Hualing Hanma 460 HP Gearbox Fast 12-speed Transmission
Overall Dimension 12000×2550×3680 mm Gross Mass 53000 Kg
Curb Mass 52870 Kg Main Beam Layer High-strength Variable Cross-section Double-layer Main Beam
Axle Quantity 5 Axles (10×4) Vehicle Wheelbase 1850+3725+1375+1350 (mm)
Front Axle Capacity 7.5 tons Rear Axle Capacity 16 tons Rear Axle
Anti-lock Braking System ABS Fuel Tank Capacity 400L All-aluminum Fuel Tank
Tire Quantity 12+1 Tire Specification Drive Wheel: 12.00R20; Non-drive Wheel: 385/65R22.5
 Crane Configuration 　 　 　
Max. Lifting Load 100 tons at 4m Radius Working Radius 14.9 M
Outrigger Extension Stroke 8300 mm Hydraulic Pump Displacement 108cc/r
Hydraulic Pump Pressure 30MPa Slewing Angle 360°
Steel Plate Material HG785 Welding Wire ER80-G
Oil Cylinder 27SiMn, Internal Precision Machining, Imported Combined Oil Seal Oil Pipe 45MPa National Standard Seamless Tube & Hose
Valve Block Proportional Valve DV4/6, Balance Valve 120L 3/4, Sequence Valve 3/4, Selector Valve G3/4, Hydraulic Lock 3/8 20L, Supplied by Italy FLUID-PRESS Piston Pump Italy OMFB, Straight Pump 100
Slewing Motor 13500 N·M Optional Configuration Remote Control, Auxiliary Jib, Hoist, Counterweight
